Anti-Smoothened Rabbit mAb
Catalog number :AT0402
G protein-coupled receptor that probably associates with the patched protein (PTCH) to transduce the hedgehog's proteins signal. Binding of sonic hedgehog (SHH) to its receptor patched is thought to prevent normal inhibition by patched of smoothened (SMO). Required for the accumulation of KIF7 and GLI3 in the cilia.
- Overview
- Description
- Rabbit monoclonal antibody to Smoothened
- Reactivity
- Mouse, Human, Monkey, Zebrafish
- Tested applications
- WB: Use a concentration of 0.1 - 1 µg/ml. Detects a band of approximately 86 kDa (predicted molecular weight: 86 kDa).
IHC-P: Use a concentration of 10 µg/ml.
ICC/IF: Use at an assay dependent concentration.
- Properties
- Immunogen
Synthetic peptide (Human) corresponding to a region between residues 190-240 of human Smoothened. (NP_005622.1).
- Clonality
- Monoclonal, clone number: 23B7
- Isotype
- Rabbit IgG
- Form
- Liquid
Preservative: 0.05% Sodium Azide
Constituents: 0.05% BSA, PBS
- Storage instruction
- Shipped at 4°C. Upon delivery aliquot and store at -20°C or -80°C. Avoid repeated freeze / thaw cycles.
- Database links
- Entrez Gene: 6608 Human
- Entrez Gene: 319757 Mouse
- Entrez Gene: 30225 Zebrafish
- Omim: 601500 Human
- SwissProt: Q99835 Human
- SwissProt: P56726 Mouse
- Unigene: 437846 Human
- Unigene: 29279 Mouse
- Applications
- WB Image
-
All lanes : Anti-Smoothened antibody (AT0402) at 0.1 µg/ml
Lane 1 : Human heart lysate
Lane 2 : Human heart lysate with immunising peptide
Predicted band size : 86 kDa
Observed band size : 86 kDa
- IHC Image
-
Immunohistochemical analysis using formalin/PFA-fixed paraffin-embedded human brain tissue with an isotype control (top image) and AT0402, at 10µg/ml staining Smoothened (bottom image).
AT0402 staining Smoothened in 6 month-old transgenic zebrafish pancreas (Ihha overexpression) by Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections).
Sections were incubated with primary antibody (1/200) and HRP-conjugated secondary antibody colored using DAB solution. Slides were counterstained with hematoxylin.
- ICC/IF Image
- ICC/IF image of AT0402 stained HeLa cells. The cells were 4% formaldehyde fixed (10 min) and then incubated in 1%BSA / 10% normal goat serum / 0.3M glycine in 0.1% PBS-Tween for 1h to permeabilise the cells and block non-specific protein-protein interactions. The cells were then incubated with the antibody (AT0402, 1µg/ml) overnight at +4°C. The secondary antibody (green) was Alexa Fluor® 488 goat anti-rabbit IgG (H+L) used at a 1/1000 dilution for 1h. Alexa Fluor® 594 WGA was used to label plasma membranes (red) at a 1/200 dilution for 1h. DAPI was used to stain the cell nuclei (blue) at a concentration of 1.43µM.
